Specifications & Features

• X-Ray Output : 60KVP
• X-Ray Tube : KLI -0.8 – 70
• Machine Approved by : Atomic Energy Regulatory Board(AERB)
• Certification No. : AERB/30/811­
• Power Requirement : 230V ± 10% 50 Hz, 5 Amp
• Radiography Cone : Long cone covered with lead sheet from inside
• Filtration : 1.5 mm Al
• Focal Spot : 0.8 mm × 0.8 mm
• Timer : Microprocessor Based Digital Timer
• RVG : Yes, RVG Compatible
• Display : LCD Display
• Exposure Times : Radiography : 0.1 to 3.0 Sec.
• : RVG : 0.02 to 0.6 Sec.
• Exposure Switch : Cordless Remote Control
• Microprocessor based X-ray timer.
• Independent memory for Digital and Conventional Dental Radiography time selections.
• Short time exposure range starting from 0.02 sec. makes it ideal for Digital
• Radiography.
• Soft touch panel switches.
• Line voltage compensation 170 – 260 V in 12 uniform steps.
• Tube overload protection for longer tube life.
• 10 seconds time delay between two consecutive exposures.
• Audio-visual indications during exposure and in tube overload condition.
• LED indicators to indicate ready sign and Digital Radiography (RVG) selection.
• Lead coated, irremovable, long radiography cone.
• Side mounting of tube head provides high maneuverability and quick positioningṭ
